ATP5F1 Recombinant Mouse Monoclonal Antibody [A10H10-R]
Overview
Product Name
ATP5F1 Recombinant Mouse Monoclonal Antibody [A10H10-R]
Antibody Type
Recombinant Mouse Monoclonal Antibody
Immunogen
Synthetic peptide within human ATP5F1 aa 30-80.
Species Reactivity
Human, Mouse, Rat
Validated Applications
WB, IF-Cell, IHC-P
Molecular Weight
Predicted band size: 29 kDa
Positive Control
HEK-293 cell lysate, Jurkat cell lysate, 293T cell lysate, Ramos cell lysate, K-562 cell lysate, A549 cell lysate, HeLa cell lysate, Mouse heart tissue lysate, Mouse kidney tissue lysate, Rat heart tissue lysate, Rat kidney tissue lysate, HeLa, C6, human kidney tissue, mouse kidney tissue, rat kidney tissue.
Conjugation
unconjugated
Clone Number
A10H10-R
Product Features
Form
Liquid
Concentration
Storage Instructions
Shipped at 4℃. Store at +4℃ short term (1-2 weeks). Store at -20℃ long term.
Storage Buffer
PBS (pH7.4), 0.1% BSA, 40% Glycerol. Preservative: 0.05% Sodium Azide.
Isotype
IgG1
Purification Method
Protein A affinity purified.
Application Dilution
-
WB
-
1:2,000
-
IF-Cell
-
1:100
-
IHC-P
-
1:200
Target
Function
ATP synthase subunit b, mitochondrial is an enzyme that in humans is encoded by the ATP5PB gene. This gene encodes a subunit of mitochondrial ATP synthase. Mitochondrial ATP synthase catalyzes ATP synthesis, utilizing an electrochemical gradient of protons across the inner membrane during oxidative phosphorylation. ATP synthase is composed of two linked multi-subunit complexes: the soluble catalytic core, F1, and the membrane-spanning component, Fo, comprising the proton channel. The catalytic portion of mitochondrial ATP synthase consists of 5 different subunits (alpha, beta, gamma, delta, and epsilon) assembled with a stoichiometry of 3 alpha, 3 beta, and a single representative of the other 3. The proton channel seems to have nine subunits (a, b, c, d, e, f, g, F6 and 8). This gene encodes the b subunit of the proton channel. The b subunits are part of the peripheral stalk that links the F1 and FO complexes together, and which acts as a stator to prevent certain subunits from rotating with the central rotary element. The peripheral stalk differs in subunit composition between mitochondrial, chloroplast and bacterial F-ATPases. In bacterial and chloroplast F-ATPases, the peripheral stalk is composed of one copy of the delta subunit (homologous to OSCP in mitochondria), and two copies of subunit b in bacteria, or one copy each of subunits b and b' in chloroplasts and photosynthetic bacteria.
Background References
1. Wang J., Huo K., Ma L., Tang L., Li D., Huang X., Yuan Y., Li C., Wang W., Yang X. Toward an understanding of the protein interaction network of the human liver. Mol Syst Biol 7:536-536 (2011)
2. Davies K.M., Strauss M., Daum B., Kief J.H., Osiewacz H.D., Rycovska A., Zickermann V., Kuhlbrandt W. Macromolecular organization of ATP synthase and complex I in whole mitochondria. Proc Natl Acad Sci U S A 108:14121-14126 (2011)
Subcellular Location
Mitochondrion, Mitochondrion inner membrane.
Synonyms
ATP synthase F(0) complex subunit B1, mitochondrial Curated
ATP synthase peripheral stalk-membrane subunit b Curated
ATP synthase proton-transporting mitochondrial F(0) complex subunit B1
ATP synthase subunit b (ATPase subunit b)
ATP5PB
ATP5F1
Images
-
Western blot analysis of ATP5F1 on different lysates with Mouse anti-ATP5F1 antibody (HA601353) at 1/2,000 dilution.
Lane 1: HEK-293 cell lysate (20 µg/Lane)
Lane 2: Jurkat cell lysate (20 µg/Lane)
Lane 3: 293T cell lysate (20 µg/Lane)
Lane 4: Ramos cell lysate (20 µg/Lane)
Lane 5: K-562 cell lysate (20 µg/Lane)
Lane 6: A549 cell lysate (20 µg/Lane)
Lane 7: HeLa cell lysate (20 µg/Lane)
Lane 8: Mouse heart tissue lysate (40 µg/Lane)
Lane 9: Mouse kidney tissue lysate (40 µg/Lane)
Lane 10: Rat heart tissue lysate (40 µg/Lane)
Lane 11: Rat kidney tissue lysate (40 µg/Lane)
Predicted band size: 29 kDa
Observed band size: 25 kDa
Exposure time: Lane 1-7: 3 minutes; Lane 8-11: 10 seconds; ECL: K1801;
4-20% SDS-PAGE gel.
Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (HA601353) at 1/2,000 dilution was used in 5% NFDM/TBST at 4℃ overnight. Goat Anti-Mouse IgG - HRP Secondary Antibody (HA1006) at 1/50,000 dilution was used for 1 hour at room temperature. -
Immunocytochemistry analysis of HeLa cells labeling ATP5F1 with Mouse anti-ATP5F1 antibody (HA601353) at 1/100 dilution.
Cells were fixed in 4% paraformaldehyde for 20 minutes at room temperature, permeabilized with 0.1% Triton X-100 in PBS for 5 minutes at room temperature, then blocked with 1% BSA in 10% negative goat serum for 1 hour at room temperature. Cells were then incubated with Mouse anti-ATP5F1 antibody (HA601353) at 1/100 dilution in 1% BSA in PBST overnight at 4 ℃. Goat Anti-Mouse IgG H&L (iFluor™ 488, HA1125) was used as the secondary antibody at 1/1,000 dilution. PBS instead of the primary antibody was used as the secondary antibody only control. Nuclear DNA was labelled in blue with DAPI.
beta Tubulin (ET1602-4, red) was stained at 1/100 dilution overnight at +4℃. Goat Anti-Rabbit IgG H&L (iFluor™ 594, HA1122) was used as the secondary antibody at 1/1,000 dilution. -
Immunocytochemistry analysis of C6 cells labeling ATP5F1 with Mouse anti-ATP5F1 antibody (HA601353) at 1/100 dilution.
Cells were fixed in 4% paraformaldehyde for 15 minutes at room temperature, permeabilized with 0.1% Triton X-100 in PBS for 15 minutes at room temperature, then blocked with 1% BSA in 10% negative goat serum for 1 hour at room temperature. Cells were then incubated with Mouse anti-ATP5F1 antibody (HA601353) at 1/100 dilution in 1% BSA in PBST overnight at 4 ℃. Goat Anti-Mouse IgG H&L (iFluor™ 488, HA1125) was used as the secondary antibody at 1/1,000 dilution. PBS instead of the primary antibody was used as the secondary antibody only control. Counterstained with Mitotracker. Nuclear DNA was labelled in blue with DAPI. -
Immunohistochemical analysis of paraffin-embedded human kidney tissue with Mouse anti-ATP5F1 antibody (HA601353) at 1/200 dilution.
The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (HA601353) at 1/200 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX. -
Immunohistochemical analysis of paraffin-embedded mouse kidney tissue with Mouse anti-ATP5F1 antibody (HA601353) at 1/200 dilution.
The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (HA601353) at 1/200 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX. -
Immunohistochemical analysis of paraffin-embedded rat kidney tissue with Mouse anti-ATP5F1 antibody (HA601353) at 1/200 dilution.
The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (HA601353) at 1/200 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.
Please note: All products are "FOR RESEARCH USE ONLY AND ARE NOT INTENDED FOR DIAGNOSTIC OR THERAPEUTIC USE"
Citation
-
Targeting renal tubular WWP2 to restore mitochondrial OXPHOS integrity retards the AKI-to-CKD transition
Journal: Molecular Therapy
DOI: 10.1016/j.ymthe.2025.11.022
IF: 12
Application: WB
Reactivity: Mouse
Publish date: 2025 Nov
