NaV1.7 Rabbit Polyclonal Antibody

Usd: 315

Specification

Bulk Order Quote | Customization Request

Catalog# ER1706-57

NaV1.7 Rabbit Polyclonal Antibody

Application

  • IF-Cell

  • IHC-P

Reactivity

  • Human

  • Rat

Conjugation

  • unconjugated

Overview

Product Name

NaV1.7 Rabbit Polyclonal Antibody

Antibody Type

Rabbit Polyclonal Antibody

Immunogen

Synthetic peptide within Human NaV17 aa 1,939-1,988 / 1,988.

Species Reactivity

Human, Rat

Validated Applications

IF-Cell, IHC-P

Molecular Weight

Predicted band size: 226 kDa

Positive Control

SH-SY5Y, A549, Hela, human placenta tissue, rat testis tissue, mouse colon tissue, human liver tissue.

Conjugation

unconjugated

RRID

AB_3069072

Product Features

Form

Liquid

Concentration

Storage Instructions

Shipped at 4℃. Store at +4℃ short term (1-2 weeks). It is recommended to aliquot into single-use upon delivery. Store at -20℃ long term.

Storage Buffer

1*PBS (pH7.4), 0.2% BSA, 50% Glycerol. Preservative: 0.05% Sodium Azide.

Isotype

IgG

Purification Method

Immunogen affinity purified.

Application Dilution

  • IF-Cell

  • 1:50-1:200

  • IHC-P

  • 1:50-1:600

Target

Function

Mediates the voltage-dependent sodium ion permeability of excitable membranes. Assuming opened or closed conformations in response to the voltage difference across the membrane, the protein forms a sodium-selective channel through which Na(+) ions may pass in accordance with their electrochemical gradient. It is a tetrodotoxin-sensitive Na(+) channel isoform. Plays a role in pain mechanisms, especially in the development of inflammatory pain.

Background References

1. Henningsen K et al. Candidate hippocampal biomarkers of susceptibility and resilience to stress in a rat model of depression. Mol Cell Proteomics 11:M111.016428 (2012).

2. Weiss J et al. Loss-of-function mutations in sodium channel Nav1.7 cause anosmia. Nature 472:186-90 (2011).

Sequence Similarity

Belongs to the sodium channel (TC 1.A.1.10) family. Nav1.7/SCN9A subfamily.

Tissue Specificity

Expressed strongly in dorsal root ganglion, with only minor levels elsewhere in the body, smooth muscle cells, MTC cell line and C-cell carcinoma. Isoform 1 is expressed preferentially in the central and peripheral nervous system. Isoform 2 is expressed preferentially in the dorsal root ganglion.

Post-translational Modification

Phosphorylation at Ser-1490 by PKC in a highly conserved cytoplasmic loop increases peak sodium currents.; Ubiquitinated by NEDD4L; which may promote its endocytosis. Does not seem to be ubiquitinated by NEDD4.

Subcellular Location

Plasma membrane. In neurite terminals.

UNIPROT

SwissProt: Q15858 Human

SwissProt: O08562 Rat

Synonyms

ETHA antibody

GEFSP7 antibody

hNE Na antibody

hNE-Na antibody

hNENa antibody

NE NA antibody

NENA antibody

Neuroendocrine sodium channel antibody

Peripheral sodium channel 1 antibody

PN1 antibody

Expand

Images

  • ICC staining NaV1.7 in SH-SY5Y cells (green). The nuclear counter stain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilised with 0.25% Triton X100/PBS.

    ICC staining NaV1.7 in SH-SY5Y cells (green). The nuclear counter stain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilised with 0.25% Triton X100/PBS.

  • ICC staining NaV1.7 in A549 cells (green). The nuclear counter stain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilised with 0.25% Triton X100/PBS.

    ICC staining NaV1.7 in A549 cells (green). The nuclear counter stain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilised with 0.25% Triton X100/PBS.

  • ICC staining NaV1.7 in Hela cells (green). The nuclear counter stain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilised with 0.25% Triton X100/PBS.

    ICC staining NaV1.7 in Hela cells (green). The nuclear counter stain is DAPI (blue). Cells were fixed in paraformaldehyde, permeabilised with 0.25% Triton X100/PBS.

  • Immunohistochemical analysis of paraffin-embedded human liver tissue with Rabbit anti-NaV1.7 antibody (<a href="/products/ER1706-57" style="font-weight: bold;text-decoration: underline;">ER1706-57</a>) at 1/600 dilution.<br /><br />The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH<sub>2</sub>O and PBS, and then probed with the primary antibody (<a href="/products/ER1706-57" style="font-weight: bold;text-decoration: underline;">ER1706-57</a>) at 1/600 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

    Immunohistochemical analysis of paraffin-embedded human liver tissue with Rabbit anti-NaV1.7 antibody (ER1706-57) at 1/600 dilution.

    The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (ER1706-57) at 1/600 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

  • Immunohistochemical analysis of paraffin-embedded mouse colon tissue with Rabbit anti-NaV1.7 antibody (<a href="/products/ER1706-57" style="font-weight: bold;text-decoration: underline;">ER1706-57</a>) at 1/600 dilution.<br /><br />The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH<sub>2</sub>O and PBS, and then probed with the primary antibody (<a href="/products/ER1706-57" style="font-weight: bold;text-decoration: underline;">ER1706-57</a>) at 1/600 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

    Immunohistochemical analysis of paraffin-embedded mouse colon tissue with Rabbit anti-NaV1.7 antibody (ER1706-57) at 1/600 dilution.

    The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (ER1706-57) at 1/600 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

  • Immunohistochemical analysis of paraffin-embedded human placenta tissue using anti-NaV1.7 antibody. Counter stained with hematoxylin.

    Immunohistochemical analysis of paraffin-embedded human placenta tissue using anti-NaV1.7 antibody. Counter stained with hematoxylin.

  • Immunohistochemical analysis of paraffin-embedded rat testis tissue using anti-NaV1.7 antibody. Counter stained with hematoxylin.

    Immunohistochemical analysis of paraffin-embedded rat testis tissue using anti-NaV1.7 antibody. Counter stained with hematoxylin.

Please note: All products are "FOR RESEARCH USE ONLY AND ARE NOT INTENDED FOR DIAGNOSTIC OR THERAPEUTIC USE"
